What should be checked if the traction orchard air delivery pesticide machine overturns?
How to deal with the overturning of the tractor driven fruit tree air delivery sprayer?

When many fruit farmers use the traction type fruit tree pneumatic pesticide sprayer for spray operation, our traction type pneumatic pesticide sprayer overturns due to the excessive horsepower of the tractor or too fast walking speed. In addition, our orchard terrain belongs to the slope. In terms of all external factors, the main reason is due to the high speed of the vehicle. It works fine when accelerating in a straight line, but when turning, we still don't slow down. In addition, the inertia of the liquid in the medicine bucket exacerbates the risk of overturning. Therefore, when using it, remember to slow down and cut off the PTO speed when turning or turning.

1) Medication pump: Check if there is any damage to the medication pump caused by excessive force on the position of the connection between the medication pump and the drive shaft. This is very important. If the force causes the position of the drive shaft of the medication pump to shift, remember to stop the machine and check

2) Gearbox: Because our gearbox is directly connected to the fan through a long shaft connecting the fan blades, if there is any damage, remember to stop the machine for inspection

3) Fan section and blade section: If our fan section is displaced due to continuous rolling caused by vehicle rollover, we must immediately stop the machine for inspection; Another issue is whether there is any impact or serious displacement when our fan blades are manually transferred. If there is displacement, we must stop the machine, indicating that our gearbox output shaft has been displaced due to stress and must be replaced before proceeding with the operation.

4) At the same time, it is necessary to check whether the nozzle and some plastic accessories are damaged. If there is any damage, it is necessary to confirm the damaged accessories and replace them uniformly before proceeding with the operation.

The above is our discussion with users about the reasons for the overturning of the traction air delivery medicine machine and how to determine and solve it.
